- Công nghệ in nhiệt
- Tốc độ in : 50mm/s
- Cổng kết nối: USB mini, Bluetooth
- Khổ giấy 80mm
- Sử dụng pin Lithium 7.4VDC/ 2000mmA
| Printing | |
| Printing method | Direct thermal |
| Printing width | 72mm |
| Column capacity | 8dots/mm, 384dots/line |
| Printing speed | 50mm/s |
| Interface | USB+Serial+Bluetooth |
| Printing paper | 79.5±0.5mm×φ40mm |
| Line spacing | 3.75mm (Adjustable by commands) |
| Column number | 58mm paper: Font A - 32 columns/Font B - 42 columns/ Chinese,traditional Chinese - 16 columns |
| Character size | ANK，Font A：1.5×3.0mm（12×24 dots） Font B：1.1×2.1mm（9×17 dots） Chinese,traditional Chinese:3.0×3.0mm（24×24 dots） |
| Barcode Character | |
| Extension character | |
| Sheet |
PC347（Standard Europe、Katakana、PC850（Multilingual、 PC860（Portuguese、PC863（Canadian-French、 PC865（Nordic、West Europe、Greek、Hebrew、East Europe、Iran、WPC1252、 PC866（Cyrillic#2）、PC852（Latin2）、PC858、IranII、Latvian、Arabic、PT151（1251） |
| Barcode types | 1D Barcode: UPC-A/UPC-E/JAN13（EAN13）/JAN8（EAN8）/ CODABAR/ITF/CODE39/CODE93/CODE128 |
| 2D Barcode: QR CODE/PDF417 | |
| Input buffer | 32k bytes |
| NV Flash | 64k bytes |
| Power | Power supply |
| Power source | Input：AC 110V/240V, 50～60Hz |
| Output：DC 9V-2A | |
| Physical characteristics | |
| Weight | 0.26KG |
| Dimension | 108.5×105×48mm(D x W x H) |
| Environmental Requirements | |
| Work environment | Temperature (0～45) humidity(10～80%) |
| Storage environment | Temperature(-10～60℃) humidity(10～90%) |
| Reliability | |
| Printer head life | 50KM |
